Code locks
Works with electromagnetic locks and access control systems Controls other electrical or alarm devices 1 Relay output Supports cards and PIN codes (10 000 combinations, 2000 PINs) Remembers saved codes and parameters in case of the power failure Backlit keyboard Surface mounting Anti-tamper protection Detection of the doors opening Adjustable door opening time and alarm hold time.
| General information: | |
|---|---|
| Touch keyboard: | No |
| Doorbell button: | No |
| Type of power supply: | 12V DC |
| Operating mode: | proximity tag / proximity tag + card / proximity tag or code |
| Degree of protection (IP): | 20 |
| Type of transmission: | wired |
| Number of relay outputs: | 1 |
| Nominal voltage: | 12V DC |
| Max. number of users: | 1000 |
| Installation: | surface mounting |
| Dimensions - depth: | 120 mm |
| Proximity reader: | Yes |
| Dimensions - width: | 50 mm |
| Keypad: | Yes |
| Dimensions - height: | 27 mm |
| Other features: | anti-tamper protection |
| Frequency: | 125 kHz |
| Temporary access can be granted: | No |
| Permanent access can be granted: | No |
| Backlight: | No |
| Fingerprint reader: | No |
