Wall sensors
The Tuya Wi-Fi motion sensor is an advanced device alerting the users of the motion detected. It may also switch on the lighting system to optimize the use of artificial lighting and to inform the owner of the presence of people in the building.
The sensor operates at a nominal voltage of 230V AC and a frequency of 50Hz. The maximum switching power is up to 1200W, including 300W for LED lighting. The maximum switching time is 60s, with an economical energy consumption of only 0.5W. The device covers a 3-year warranty.
The sensor is dust and moisture resistant (IP65), making it ideal for both indoor and outdoor use. The unit is surface mounted, either on the ceiling or on the wall.
The two built-in sensors increase the precision of motion detection. The maximum range straight ahead is 12m. The device detects movement at a speed of 0.6-1.5 m/s. The light intensity, adjustable from 5 to 2000 lux (5, 10, 50, 150, 2000 lux), allows the device to adapt to different lighting conditions. In addition, the 360°/180° detection angle provides a wide monitoring area.
The motion sensor may be integrated with the Tuya Smart system by connecting to a Wi-Fi network. This facilitates to easily create an alarm system and lighting control system in homes or offices without the need for additional devices. The app simply needs to be installed on the smartphone and connected to the device. This makes it convenient to control the motion sensor from anywhere in the world.
Made of high-quality plastic in black. It is durable and aesthetically pleasing. The dimensions are 52x124x80 mm.
| General information: | |
|---|---|
| Model: | Czujnik ruchu |
| Sensor type: | Podczerwień pasywna |
| Scan angle [°]: | 360 |
| Optimum mounting height [m]: | 1,8 - 2,5 |
| Max. reach frontally [m]: | 12 |
| Detection moving speed [m/s]: | 0,6 - 1,5 |
| Response value luminosity adjustable: | Tak |
| Light intensity adjustment range [lux]: | 5, 10, 50, 150, 2000 |
| Mounting method: | Montaż natynkowy |
| Suitable for ceiling mounting: | Tak |
| Suitable for wall mounting: | Tak |
| Connection type: | Zacisk śrubowy |
| Material: | Tworzywo sztuczne |
| Material quality: | Tworzywo termoplastyczne |
| Colour: | Czarny |
| Degree of protection: | IP65 |
| Voltage type: | AC |
| Frequency [Hz]: | 50 |
| Nominal voltage [V]: | 230 |
| Min. switch-on time [s]: | 5 |
| Max. duty cycle [min]: | 60 |
| Detection angle horizontal [°]: | 180 |
| Pivoting range sensor, vertical [°]: | -90 - +90 |
| Max. switching power [W]: | 1200 |
| Max. switching power LED [W]: | 300 |
| Power consumption [W]: | 0,5 |
| Relay output: | Tak |
| Temperature [°C]: | -20 - +40 |
| Working humidity: | <93% |
| Width [mm]: | 52 |
| Height [mm]: | 124 |
| Depth [mm]: | 80 |
| Weight [g]: | 160 |
| Powered by TUYA: | Tak |
| Wi-Fi: | Tak |
| Wi-Fi Standard: | IEEE 802.11 b/g/n |
| Wi-Fi Frequency [GHz]: | 2.4 |
| Wi-Fi Power: | ≤0,2W |
