OR-DB-FX-152
Archived product

Description

General information:
Wireless: tak
Max. transmission range [m]: 400
Frequency [MHz]: 433.92
Possibility of extension by an additional transmitters: tak
Other features: learning system
Receiver:
Type of current (receiver): DC
Nominal voltage [V]: 4.5
Battery - type and quantity (receiver): 3xAA
Built-in battery (receiver): nie
Electricity consumption [W]: <100mA
Number of ringtones: 58
Loudness [dB]: 110
Volume adjustment [dB]: tak
Volume adjustment range [dB]: 0-110
Optical indication: tak
Mounting method: Montaż natynkowy
Degree of protection (IP): IP20
Housing material (receiver): Tworzywo sztuczne
Colour housing: Biały
Width (receiver) [mm]: 80
Height (receiver) [mm]: 80
Depth (receiver) [mm]: 25
Transmitter:
Type of current (transmitter): DC
Nominal voltage (transmitter) [V]: 6
Battery - type and quantity (transmitter): 2xCR2016
Built-in battery (transmitter): tak
Transmitter max. power [mW]: <10
Degree of protection (IP) (transmitter): IP44
With name plate: tak
Housing material (transmitter): Tworzywo sztuczne
Colour (transmitter): Biały
Width (transmitter) [mm]: 30
Height (transmitter) [mm]: 85
Depth (transmitter) [mm]: 18
:

Files to download

File category File language File type File update date
Product data sheetPLpdf2025-07-16 16:54:21Download
Product data sheetENpdf2025-07-16 17:05:00Download
User manualSLpdf2025-06-25 15:28:55Download
User manualPL, EN, DEpdf2025-06-25 15:28:55Download
