Ring terminals
The non-insulated blade terminal is designed for quick and reliable connecting of electrical cables. Suitable for multicore and flexible cables with a nominal cross-section of 1 to 2,5 mm². The connector guarantees a stable connection thanks to its 6.3 mm flat end and 0.7 mm thick conductive material.
Made of tin-coated brass for corrosion resistance and good electrical conductivity. The blue PVC insulation increases safety of use.
The product meets the requirements of EN 60352-2:2006.
The pack contains 100 pieces.
| General information: | |
|---|---|
| Model: | Wtyczka (wsuwka) |
| Plug dimensions: | Płaski 6,3x0,7 mm |
| Pin width (flat-pin shape terminal) [mm]: | 6.3 |
| Nominal cross section [mm²]: | 1-2,5 |
| Colour: | Niebieski |
| Material insulation: | Polichlorek winylu (PVC) |
| Material: | Mosiądz |
| Surface protection: | Cynowanie |
| Thickness of conductive material [mm]: | 0.7 |
| Suitable for stranded conductors: | Tak |
| Suitable for fine strand conductors: | Tak |
| Number of pieces in the package [szt.]: | 100 |
| Compliance with standards: | EN 60352-2:2006 |
